ابعاد :
|
50 × 350 × 460 میلیمتر
|
|
وزن :
|
5500 گرم
|
|
نوع سوییچ :
|
10/100/1000Mbp/s
|
|
قابلیت برنامهریزی و مدیریت :
|
|
|
توضیحات مدیریت :
|
Web-based Management
VLAN
QoS
Syslog
Telnet
RMON I, II
SNMP v1, v2c, v3
DHCP
CLI
|
|
تعداد پورتها :
|
24 عدد
|
|
نوع پورتها :
|
Network (RJ-45) Ports
|
|
ویژگیهای پورت :
|
24 x Gigabit Ethernet Network
4 x Gigabit Ethernet Expansion Slot
|
|
استانداردها :
|
IEEE Standards: 802.1D 802.1p 802.1Q 802.1s 802.1w 802.1X 802.1ab 802.3ad 802.3af 802.3at 802.3ah 802.3x 802.3 802.3u 802.3ab 802.3z 802.3az 802.1ae 802.3ae 802.1ax Safety: UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition AS/NZS 60950-1 EMC: 47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A EN55024 CISPR24 EN300386 KN24
|
|
کنترل دسترسی :
|
CLI, HTTP, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, TFTP, Telnet
|
|
سرعت انتقال :
|
216 Gbps, 71.4 Mpps
|
|
ظرفیت سوئیچینگ :
|
Virtual interfaces (VLANs): 1023
|
|
توضیحات نشانگر LED :
|
Port transmission speed, port duplex mode, system, status, link/activity
|
|
نشانگر LED :
|
|
|
QoS :
|
ARP support, Access Control List (ACL) support, Jumbo Frames support, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NetFlow, Port Aggregation Protocol (PAgP) support, RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Cisco EnergyWise technology, Shaped Round Robin (SRR), Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), Unicast Reverse Path Forwarding (URPF), VLAN support, auto-negotiation, auto-uplink (auto MDI/MDI-X), layer 2 switching, trunking, DHCP support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Hot Standby Router Protocol (HSRP) support, IPv4 support, IPv6 support
|
|
منبع تغذیه :
|
AC 120/230 V
|
|
مشخصات :
|
Subtype Gigabit Ethernet
Ports 24 x 10/100/1000 + 4 x Gigabit SFP
Performance Switching capacity: 216 Gbps
Forwarding performance (64-byte packet size): 71.4 Mpps
Capacity Virtual interfaces (VLANs): 1023
Jumbo Frame Support 9216 bytes
Max Units In A Stack 8
Authentication Method Kerberos, RADIUS, Secure Shell (SSH), TACACS+
RAM 512 MB
Max Units In A Stack 8
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Status Indicators Port transmission speed, port duplex mode, system, status, link/activity
Jumbo Frame Support 9216 bytes
ManufacturerCisco
|
